Product Overview
The Turck IR-B8-M18P-E2-M is a high-performance infrared photoelectric sensor designed for reliable object detection in demanding industrial environments. Featuring an M18 cylindrical stainless steel housing with IP67/IP69K protection, this sensor is engineered to withstand harsh conditions such as dust, moisture, vibration, and high-pressure washdowns. Utilizing infrared light technology, it offers precise detection of objects up to 8 meters, depending on the target surface and environmental factors. The IR-B8-M18P-E2-M operates on a 10–30 V DC supply and provides a configurable PNP or NPN output via an M12 connector. Ideal for logistics, packaging, and automotive applications, this sensor ensures accurate, repeatable performance in dynamic automation systems.
Key Technical Parameters
- Detection Range: Up to 8 meters (adjustable based on target reflectivity).
- Light Source: Infrared LED with modulated beam for interference immunity.
- Supply Voltage: 10–30 V DC (±10%) with reverse polarity protection.
- Output Type: Configurable PNP/NPN transistor (NO/NC), 100 mA max load current.
- Response Time: ≤1 ms for high-speed detection.
- Housing Material: Stainless steel (316L) with chemical-resistant coating.
- Operating Temperature: -25°C to +70°C (-13°F to +158°F).
- Protection Class: IP67/IP69K (dustproof, waterproof, and high-pressure resistant).
- Connector: M12 4-pin quick-disconnect (E2 variant).
- Certifications: CE, UL, cULus, RoHS, and IEC 60947-5-2 compliance.
Typical Applications
The IR-B8-M18P-E2-M is widely used in industries requiring precise, long-range object detection:
- Logistics & Warehousing: Detecting pallets, boxes, or AGVs on conveyor systems.
- Packaging Machinery: Verifying product presence on filling, labeling, or sealing lines.
- Automotive Manufacturing: Monitoring part alignment in robotic assembly or welding cells.
- Food & Beverage: Sanitary detection of containers or lids in washdown environments.
- Material Handling: Position sensing in automated storage and retrieval systems (AS/RS).
Its infrared technology minimizes interference from ambient light, ensuring reliable operation in diverse settings.
Competitive Advantages
- Long-Range Detection: Adjustable sensing up to 8 meters for flexible application design.
- Rugged Construction: Stainless steel housing resists corrosion, impacts, and extreme temperatures.
- High Immunity to Interference: Modulated infrared beam reduces false triggers from ambient light or dust.
- Easy Configuration: Teach-in function and potentiometer for quick sensitivity adjustments.
- Low Maintenance: Sealed design and durable components extend service life in harsh conditions.
Core Functionalities
The IR-B8-M18P-E2-M delivers advanced features for industrial reliability:
- Adjustable Sensitivity: Fine-tune detection thresholds via built-in potentiometer or remote teach-in.
- Beam Diagnostics: Status LEDs (green for power, yellow for output) enable real-time troubleshooting.
- Short-Circuit Protection: Safeguards output circuits from overloads or wiring faults.
- Temperature Stability: Maintains accuracy across a broad operational temperature range.
- IO-Link Compatibility (if applicable): Enables remote parameterization and integration into smart factories.
| Parameter Category | Specification / Attribute |
| Product Type | Background Suppression Photoelectric Sensor (Fixed Field) |
| Model Number | IR-B8-M18P-E2-M |
| Sensing Principle | Infrared (IR) Light (880 nm) with Background Suppression (BGS) Technology |
| Detection Method | Reflective (Object reflects emitted light; BGS ignores distant backgrounds) |
| Sensing Range | Max. 150 mm (adjustable via teach-in; optimized for dark/light objects) |
| Reference Target | White matte paper (90% reflectivity) |
| Light Source | Pulsed infrared LED (Visible red pilot beam) |
| Housing Material | Stainless steel (V4A / AISI 316L) |
| Housing Size | M18 × 1 barrel |
| Connection Type | M12 × 1, 4-pin connector (P-coded) |
| Output Configuration | PNP, Normally Open (NO) (Suffix "P" = PNP) |
| Output Function | Switching output (NO) |
| Supply Voltage (VDC) | 10–30 VDC (±10%) |
| Rated Current | ≤ 100 mA |
| No-Load Current | ≤ 15 mA |
| Voltage Drop (Max) | ≤ 2 V |
| Switching Frequency | ≤ 500 Hz |
| Response Time | ≤ 1 ms |
| Protection Rating | IP67 / IP69K (Dust-tight, high-pressure/steam washdown capable) |
| Ambient Temp. Range | -40°C to +70°C |
| Storage Temp. Range | -40°C to +85°C |
| Hysteresis | ≤ 10% of sensing range |
| Repeat Accuracy | ≤ 0.5 mm |
| Operating Indicator | Green LED (Power/status), Yellow LED (Output state) |
| Teach Function | Integrated teach-in button (Sets switching threshold) |
| Background Suppression | Fixed cutoff distance (ignores objects beyond set point) |
| Object Detection | Detects objects regardless of color, texture, or reflectivity (within range) |
| Material Compatibility | Metals, plastics, wood, glass, liquids, opaque/translucent materials |
| EMC Immunity | EN 60947-5-2: ≥ 20 V/m (26 MHz–1 GHz) |
| Vibration Resistance | 10–55 Hz @ 1.5 mm amplitude (IEC 60068-2-6) |
| Shock Resistance | 100 m/s² (30g), 6 ms, 3 axes (IEC 60068-2-27) |
| Electrical Protection | Reverse polarity, short-circuit, overload protection |
| Compliance & Approvals | CE, cULus (UL 508), EAC, RoHS 3, IEC 60947-5-2 |
| Mounting | Bracket or threaded (M18 × 1) |
| Weight | ~90 g (sensor only) |
